Part No.
|
ST1129L
|
ST1129U
|
SC1029L
|
|
Display
|
2.9-inch Glass ePaper
|
2.9-inch Glass ePaper
|
2.9-inch Flexible ePaper
|
|
Display Area
|
66.9mm x 29.06mm
|
66.9mm x 29.06mm
|
61.5mm x 41.0mm
|
|
Pixel
|
296 x 128 112dpi
|
296 x 128 112dpi
|
300 x 200 123dpi
|
|
Electric Power
|
Wireless Charging (Battery not required)
|
Wireless Charging (Battery not required)
|
Wireless Charging (Battery not required)
|
|
Data Memory (byte)
|
Card Memory (FeRAM) 944 User Memory (Flash) 16,384
|
Card Memory (FeRAM) 944 User Memory (FeRAM) 1,024 User Memory (Flash) 16,384
|
Card Memory (FeRAM) 944 User Memory (Flash) 16,384
|
|
Communication (NFC)
|
ISO/IEC 18092, JISX6319-4 compliant
|
ISO/IEC 18092, JISX6319-4 compliant
|
ISO/IEC 18092, JISX6319-4 compliant
|
|
Communication (UHF)
|
-
|
ISO/IEC 18000-63 (EPC Global Class 1)
|
-
|
|
NFC Communication Distance (mm)
|
USB Desktop Reader: 10 AIOI SC2101 Reader: 30
|
USB Desktop Reader: 10 AIOI SC2101 Reader: 30
|
USB Desktop Reader: 10 AIOI SC2101 Reader: 30
|
|
UHF Communication Distance
|
-
|
Maximum Reading Distance: 1.5m (When using 1W R/W)
|
-
|
|
Display Rewritable Times
|
More than 1 million times
|
More than 1 million times
|
More than 1 million times
|
|
Operating Temperature/Humidity
|
0℃ to 50℃ / 0% to 80% (Non condensing)
|
0℃ to 50℃ / 0% to 80% (Non condensing)
|
0℃ to 50℃ / 0% to 80% (Non condensing)
|
|
ePaper Display Speed (s)
|
0. 5 (8℃ or higher) 1.0 (0-7℃) 1.5 (-1℃ or lower)
|
0.98 (8℃ or higher) 2.4 (0-7℃) 3.2 (-1℃ or lower)
|
1.5 (40℃ or higher) 2.0 (16-39℃) 3.2 (6-15℃) 5.6 (0-5℃)
|
|
ePaper Refresh Display Speed (s)
|
0.98 (8℃ or higher) 2.4 (0-7℃) 3.2 (-1℃ or lower)
|
Same as above
|
Same as above
|
|
Full Screen Transfer Display (s) *USB Reader, Room Temperature
|
about 2.6 (2.02 + 0.5) (Including image data transmission)
|
3.0 (2.02 +0.98) (Including image data transmission)
|
4.8 (2.8 +2.0) (Including image data transmission)
|
|
Display Specified String on ePaper Display (s) *USB Reader, Room Temperature
|
about 1.6 (1.02 + 0.5) (Including character data transmission)
|
2.0 (1.02 +0.98) (Including character data transmission)
|
N/A
|
|
Dustproof/Waterproof Level
|
IP55
|
IP55
|
IP56
|
|
External Dimensions
|
93.0mm x 57.0mm x 8.0mm
|
99.0mm x 63.0mm x 8.0mm
|
85.6 mm x 54.0mm x 3.65mm
|
|
Net Weight
|
About 40g
|
About 48g
|
About 20g
|
|
|
|
|
|
